HOME > Products > Seeder (Soybean)DRP-2004SB MODEL
첨부파일
link
Content
Model name : Seeder (Soybean/for tractor)
Working crop : Soybean (for paddy soybean)
Characteristics
Specifications/Application
| Model Name | DRP-2004SB |
DRP-3006SB |
|
|---|---|---|---|
| Specification | 4 rows (2 ridges) |
6 rows (3 ridges) |
|
| Size | Length(mm) | 2440 | 2440 |
| Width(mm) | 2500 | 3040 | |
| Height(mm) | 1860 | 1860 | |
| Weight(kg) | 1180 | 1350 | |
| Structure | Driving method | Ground wheel | Ground wheel |
Ridge forming device |
Round ridge forming plate |
Round ridge forming plate |
|
Soil crushing device |
Rotary type |
Rotary type |
|
Soil crushing width (cm) |
138 |
198 | |
Seed discharge device |
Disk type |
Disk type |
|
Seeding method |
For use with both spot seeding and |
For use with both spot seeding and |
|
Inter-row spacing |
30~60cm |
30~60cm |
|
Seeding interval |
15~37cm |
15~37cm |
|
Seeding interval |
Sprocket replacement type (11 steps) |
Sprocket replacement type (11 steps) |
|
| Other structures | Spray pump | power pump | power pump |
| Liquid tank capacity | 200L×2ea(400L) | 200L×2ea(400L) | |
Nozzle diameter × number of nozzles |
1.4mm×8ea | 1.4mm×10ea | |
| Ridge size (width × height) | (100×30) cm | (80×30) cm | |
| Work efficiency | 19.8min/10a | 13.6min/10a | |
| Recommended horsepower (HP) | 90 HP or more | 120 HP or more | |
| Usage and other features | Seeding soybeans in paddy-fields / Attaching cameras and monitor |
Seeding soybeans in paddy-fields / Attaching cameras and monitor |
|
Working photograph/video
Soybean seeder working scene
(DRP-2004SB)
Soybean seeder working scene
Soybean seeder working scene
Soybean seeder working scene
(DRP-3006SB)
Soybean seeder working scene
